PDB-code
| Kinase structure | |
| Kinase: | VRK1 |
| Family: | VRK |
| Group: | CK1 |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2275 |
| PDB: | 6BP0 |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2017-12-06 |
| Chain: | A |
| (Alternate) Model: | A |
| More entries for 6BP0 | |||||
| 6BP0 | Alternative model: | A | Chain: | B | |
| 6BP0 | Alternative model: | A | Chain: | C | |
| 6BP0 | Alternative model: | A | Chain: | D | |
| 6BP0 | Alternative model: | B | Chain: | A | |
| 6BP0 | Alternative model: | B | Chain: | B | |
| 6BP0 | Alternative model: | B | Chain: | C | |
| 6BP0 | Alternative model: | B | Chain: | D | |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | - |
| G-rich loop rotation: | - |
| Quality Score: | 7.6 |
| Resolution: | 1.9 Å |
| Missing Residues: | 5 |
| Missing Atoms: | 4 |
| Ligand binding mode | ||||
| Waters | ||||
| Cluster I5 I11 | Ligand No No | Protein Yes Yes | ||
| Pocket alignment | |
| Uniprot sequence: | LPIGQGGFGCIYLCVVKVEPLFTELKFYQRAALGVPKYWGSFMIMDRFG-SDLQKIYEAYIHEHEYVHGDIKASNLLLLVDYGLA |
| Sequence structure: | LPIG_____CIYLCVVKVEPLFTELKFYQRAALGVPKYWGSFMIMDRFG_SDLQKIYEAYIHEHEYVHGDIKASNLLLLVDYGLA |
