PDB-code
| Kinase structure | |
| Kinase: | PIK3CA (p110a) |
| Family: | PIK |
| Group: | Atypical |
| Species: | HUMAN |
| IUPHAR/BPS ID: | 2153 |
| PDB: | 5SWP |
| sc-PDB: | |
| KIDFamMap: | Search |
| Release date: | 2017-02-15 |
| PubMed: | 28129991 |
| Chain: | A |
| Structural information | |
| DFG conformation: | in |
| αC-helix conformation: | in |
| G-rich loop angle (distance): | 67.3° (20Å) |
| G-rich loop rotation: | 73.7° |
| Quality Score: | 7.6 |
| Resolution: | 3.41 Å |
| Missing Residues: | 0 |
| Missing Atoms: | 0 |
| Allosteric Ligand | |
| Allosteric ligand: | 70W |
 | |
| Pocket alignment | |
| Uniprot sequence: | CRIMSSAKRPLWLIIFKNGDLRQDMLTLQIIRLRMLPYGCLVGLIEVVRSHTIMQIQCKATFI--LGIGDRHNSNIMVHIDFGHF |
| Sequence structure: | CRIMSSAKRPLWLIIFKNGDLRQDMLTLQIIRLRMLPYGCLVGLIEVVRSHTIMQIQCKATFI__LGIGDRHNSNIMVHIDFGHF |
